Product Details

Specification

The FDON slewing drive is an efficient and reliable rotational device that integrates a motor, reducer, and slewing bearing. It features high load capacity, precise control, and a compact design. Made with high-quality materials, it offers durability and corrosion resistance, making it suitable for solar tracking systems, wind power, construction machinery, and other applications. The FDON slewing drive supports various specifications to meet diverse requirements, ensuring low maintenance costs and stable performance, making it an ideal solution for high-intensity applications.

Key Features of IMO SP-I Series Slewing Drive:

Compact Design: The SP-I series features a compact design that integrates the motor, gearbox, and slewing ring into one unit, making it ideal for applications with limited space.
High Load Capacity: These drives are designed to handle heavy loads while maintaining high levels of efficiency and stability. The slewing ring and gearing system work together to ensure smooth operation under high torque conditions.
Precision and Reliability: IMO slewing drives are engineered for precision and long-lasting durability, making them suitable for demanding applications that require consistent, reliable performance over time.

Part Number	Series	Number of drives	Drive style	Module	Number Of Teeth Pinion	Number Of Wheel Teeth	Weight	Slew Drive Gear Ratio	Max Torque	Nom Torques	Max Holding Torque
SP-I 0229	SP-I Series	1 drive	Straight teeth	4	15	79	46 Kg	5.27	3002 Nm	2607 Nm	3002
SP-I 0311	SP-I Series	1 drive	Straight teeth	4	15	99	50 Kg	6.6	3762 Nm	2653 Nm	3762
SP-I 0411	SP-I Series	1 drive	Straight teeth	4	15	124	59 Kg	8.27	4712 Nm	3348 Nm	4712
SP-I 0541	SP-I Series	1 drive	Straight teeth	4	15	156	72 Kg	10.4	5928 Nm	4243 Nm	5928
SP-I 0641	SP-I Series	1 drive	Straight teeth	4	15	181	84 Kg	12.07	6878 Nm	4921 Nm	6878
SP-I 0741	SP-I Series	1 drive	Straight teeth	4	15	206	95 Kg	13.73	7828 Nm	5644 Nm	7828
SP-I 0841	SP-I Series	1 drive	Straight teeth	4	15	231	102 Kg	15.4	8778 Nm	6329 Nm	8778
SP-I 0941	SP-I Series	1 drive	Straight teeth	4	15	256	115 Kg	17.07	9728 Nm	7040 Nm	9728
SP-I 1091	SP-I Series	1 drive	Straight teeth	4	15	294	127 Kg	19.6	11172 Nm	8085 Nm	11172

When To Choose This Structure — Slewing Bearing

Sheet 01 · Selection Guide

When Should I Choose This Structure?

Before you place an order, check whether a triple-row roller slewing bearing actually matches your equipment’s duty conditions — faster than reading any spec sheet.

Your equipment needs continuous 360° rotation under high torque, heavy-load conditions — e.g. cranes, excavators, tunnel boring machines, wind turbine yaw systems.
Installation space is limited, and axial load, radial load and tilting moment must be carried by a single bearing rather than a separate bearing-plus-gearbox assembly.
The equipment needs a built-in slewing drive gear (internal or external), eliminating extra transmission components and simplifying assembly.
The operating environment involves dust, moisture, or large temperature swings, requiring a bearing with built-in sealing and lubrication channels.
The project has clear requirements for rotational accuracy and adjustable clearance — e.g. medical equipment, solar tracking mounts, precision turntables.

One-line summary

If your equipment needs to “rotate and carry heavy loads at the same time,” a triple-row roller slewing bearing is usually the most direct, integrated solution.

Typical equipment

Tower crane slewing platforms, crawler crane turntables, excavator upper structures, TBM cutterhead drives, wind turbine yaw/pitch systems, stacker-reclaimer slewing bodies.

When NOT To Choose It — Slewing Bearing

Sheet 02 · When Not To Use

When Should I NOT Choose It?

We’d rather help you find the right solution than sell you the wrong one. Here’s when a slewing bearing may not be the best fit.

If your rotational speed requirement exceeds the typical design range for slewing bearings (e.g. high-speed rotating platforms), a cross roller bearing or dedicated high-speed structure is usually a better fit.
If overall weight is extremely sensitive for the machine (e.g. drone gimbals, small precision instruments), a thin-section or angular-contact bearing combination may be lighter and more suitable.
If budget and production volume favor a standard bearing plus external gear assembly, that may be more cost-effective for non-heavy-duty, non-harsh-environment applications.
If installation space is extremely constrained and cannot meet the minimum installation diameter, confirm with our engineers whether a compact custom design is available.

Not sure which case applies to you?

Send us your equipment’s duty conditions (load / speed / space / environment) and our engineers will tell you within 24 hours whether it fits — not just try to sell you something.

Free Duty Assessment →

Required Data For Selection — Slewing Bearing

Sheet 03 · Selection Data

Required Data For Selection

You don’t need a finished drawing to get started — tell us what you already know, and our engineers will help fill in the rest.

Category	Data Needed	Why It Matters
Load Parameters	Axial load, radial load, tilting moment	Determines the number of rows and raceway design
Envelope Dimensions	Installation OD / ID, installation height, bolt hole pattern	Determines whether a standard size fits or custom sizing is needed
Speed & Duty	Operating speed (rpm), continuous or intermittent duty, environment	Affects lubrication method and seal grade
Drive Type	Internal-tooth / external-tooth / no gear (bearing only)	Determines gear module, tooth count and precision grade
Precision	Rotational accuracy, clearance range (negative clearance required?)	Affects manufacturing process and inspection standard
Drawing / Reference Part	Existing drawing, old bearing model, or competitor part number	Allows a direct 1:1 match or replication — the fastest path to selection

No drawing on hand? That’s fine — send us the parameters you know, or a photo of your old bearing’s nameplate.

Send Data Now →

Materials, Hardness, Clearance & Gear — Slewing Bearing

Sheet 05 · Material & Process

Materials / Hardness / Clearance / Gear Treatment

Every batch ships with a material certificate, hardness test report and NDT report — third-party re-inspection is welcome.

01 · MATERIAL

Ring Material

42CrMo / 50Mn (specifiable)

Determines overall strength and fatigue life. Heavy-duty applications use alloy structural steel with quenching & tempering.

02 · HARDNESS

Raceway Hardness

HRC 55–62, depth customizable

Medium-frequency induction hardening gives more uniform hardness than through-hardening, avoiding soft spots.

03 · CLEARANCE

Clearance Grade

Standard or negative, P0–P6

Heavy-duty, low-speed equipment usually uses negative clearance for higher stiffness; precision equipment can go tighter.

04 · GEAR

Gear Treatment

Q&T or induction-hardened teeth

Frequent start/stop or heavy-duty drive applications benefit from hardened tooth flanks for longer life.

Related Applications — Slewing Bearing

Sheet 06 · Applications

Related Applications

Don’t see your industry? Applications go far beyond the examples below — tell us what your equipment does.

Cranes

Excavators & Construction

Wind Turbines

Solar Tracking

Port Machinery

Rotary Platforms

Real Project Case — Slewing Bearing

Sheet 07 · Project Reference

Real Project Case

More project photos, inspection reports and customer references are available on request — happy to sign an NDA if needed.

Custom triple-row roller slewing bearing manufactured for a stacker-reclaimer, Southeast Asia port project

Case File · Port Machinery

Stacker-Reclaimer Slewing Bearing — Custom Project, SE Asia

Background: The customer was using an imported triple-row roller slewing bearing with a 4-month lead time and a high price point.
Requirement: Find a faster-to-deliver alternative while keeping the original installation dimensions and load parameters unchanged.
Solution: Based on the customer’s original part drawing, we replicated the key dimensions and gear geometry 1:1, and raised raceway hardness to HRC 58–62.

45 DaysLead Time

1:1Dimensional Match

2ndRepeat Order

Slewing Bearing Model Finder

Model Finder

Slewing Bearing Model Finder

Filter 463 catalog specifications by dimension. Results update instantly — no page reload, no server round-trip.

Outer Diameter (mm)

—

Inner Diameter (mm)

—

Height (mm)

—

Geared Type

Module (mm)

Number Of Teeth

—

Matching 463 / 463 models

Model	Structure	Geared Type	OD (mm)	ID (mm)	Height	Module	Teeth	Weight (kg)

Header fixed · scroll for more rows

Frequently Asked Questions

Expert Insights and Reliable Solutions to Your Most Common Questions.

1. What types of slewing bearings does FDON GROUP provide?

FDON GROUP supplies a full range of slewing bearings to meet different industrial needs:

Single row four point contact slewing bearings Application: medium loads, precise rotation.
Double row ball bearings Application: higher radial and axial loads.
Cross roller bearings –Application: high rigidity, suitable for robots and machining centers.
Three row roller bearings – Application: extreme loads in heavy equipment.
Ball combine roller bearings –Application: precise rotational adjustment applications.
Customized bearings – tailored for specific equipment requirements.

2. How do I choose the right bearing for my application?

Typical selection parameter for FDON clients:

Load type: axial, radial, and tilting moment.

Rotation RPM: ensures long service life.

Installation space & mounting dimensions: inner/outer ring diameter, bolt circle.

Precision & rigidity requirements: critical for cranes, excavators, and robots.

FDON engineers provide professional selection guidance according to your equipment and drawings.

3. What materials does FDON GROUP use for slewing bearings?

FDON GROUP selects materials for strength, wear resistance, and long-term durability:

Slewing ring: 42CrMo, 50Mn, C45N, 40CrNiMo, C48E.

Special forging spare parts: carburized/hardened steels for gear teeth (20CrMnTi, 18CrNiMo7‑6).

Corrosion resistant: SS 304, 316L, duplex stainless steel.

Surface treatments: heat treatment, quenching, carburizing, induction hardening, and surface coating(Four-Layer Packing, Strong Anti-Rust Oil, Black Oxide Treatment, Jet Black Paint Finish, Hot-Dip Galvanizing (CGL), Electro-Galvanizing (EGL), Hot-Dip Galvanizing + Paint Finish)

4. How can FDON GROUP achieve maximum service life?

Correct installation with flat surfaces.

Proper lubrication using grease.

Avoid overloading or shock loads over capacity.

Monitor operating conditions regularly to prevent debris entry.

5. What causes abnormal noise or vibration in bearings?

Typical factors observed by FDON engineers:

Insufficient or incorrect lubrication.
(dust, metal particles) in raceways.
Rolling element or track damage.
Uneven mounting surfaces or misalignment.
Incorrect bolt torque(below grade 8.8) or preloading.

6. What are lead times and lifetime guarantee?

In-stock: 3–7 days.

Custom: 2–6 weeks depending on size, load, and precision.

Warranty: 1 year

Lifetime Free Spare Parts: Glue, seals, steel ball

7. Does FDON provide installation and technical support?

Yes — FDON GROUP offers:

Detailed installation manuals.

Online engineering support.

Guidance for lubrication, maintenance, and troubleshooting solution.

8. How do FDON Group differ from competitors?

Full range of materials and heat treatments for various load conditions.

High precision and strict quality inspection standards.

Engineering support before and after delivery.

Customization to exact equipment requirements.

Proven performance in cranes, excavators, robotics, wind turbines, and heavy machinery etc.
